Carbide tipped circular saw blades – Amada
Disposable carbide tipped circular saw blades designed for accurate cuts at a higher cutting rate. This blade features the highest quality sawing grade of carbide.
FEATURES
- Highest quality grade of carbide tip material for sawing
- State-of-the-art manufacturing equipment
- Tested and proven body material
- Unmatched accuracy and consistency from tooth to tooth on blade to blade
- Pioneers in the manufacturing and development of carbide blades
Benefits
- Longest possible blade life
- Higher cutting rate
- Minimal or no deflection during cutting operation
- Lowest cost-per-cut in all types of material
- Minimal burr due to consistent chip-Load
- Accurate cuts with a high quality surface finish
TCB-CR
Carbide tipped circular saw blade suitable for cutting general mild steel materials such as structural steel.
Target materials
Structural alloys and structural carbon steels having a carbon content of 0.45% or more.
Features
Cermet tipped
Tips with excellent wear resistance and deposit resistance.
Stable life and good cutting quality for cutting carbon steel and alloy steel materials.
| Model | Blade Type | Size |
|---|---|---|
| CM75 | TCB-CR | 285 mm x 2.0 mm x 60 teeth |
| TCB-CR | 285 mm x 2.0 mm x 80 teeth | |
| CM100 | TCB-CR | 360 mm x 2.25 mm x 60 teeth |
| TCB-CR | 360 mm x 2.25 mm x 80 teeth | |
| TCB-CR | 360 mm x 2.25 mm x 100 teeth | |
| CM150 | TCB-CR | 460 mm x 2.7 mm x 40 teeth |
| TCB-CR | 460 mm x 2.7 mm x 60 teeth | |
| TCB-CR | 460 mm x 2.7 mm x 80 teeth | |
| TCB-CR | 460 mm x 2.7 mm x 100 teeth |
TCB-TI
Titanium-coated circular saw blade with excellent wear resistance
Application
- Cutting of general hard steel materials.
Material of tooth tips
- Carbide (and coated)
Target materials
- Structural alloys, pipes, special purpose steels (except for stainless steels and heat-resisting steels) and structural carbon steels having a carbon content of 0.4% or less.
Features
- Carbide tipped in combination with original coating for high toughness.
- This model is excellent in both chipping resistance and wear resistance. Stable life and good cutting quality is ensured in the cutting of high carbon steel materials.
| Model | Blade Type | Size |
|---|---|---|
| CM75 | TCB-TI | 285 mm x 2.0 mm x 60 teeth |
| TCB-TI | 285 mm x 2.0 mm x 80 teeth | |
| CM100 | TCB-TI | 360 mm x 2.25 mm x 60 teeth |
| TCB-TI | 360 mm x 2.25 mm x 80 teeth | |
| TCB-TI | 360 mm x 2.25 mm x 100 teeth | |
| CM150 | TCB-TI | 460 mm x 2.7 mm x 40 teeth |
| TCB-TI | 460 mm x 2.7 mm x 60 teeth | |
| TCB-TI | 460 mm x 2.7 mm x 80 teeth | |
| TCB-TI | 460 mm x 2.7 mm x 100 teeth |
TCB-CB
Circular saw blade suitable for cutting general mild steel materials
Target materials
- Structural carbon steels, structural alloys and pipes.
Features
- Carbide tipped
- Carbide tips with high toughness are used. This model is excellent in chipping. resistance, applicable to a wide range of materials and suitable for cutting various steel materials.
| Model | Blade Type | Size |
|---|---|---|
| CM75 | TCB-CB | 285 mm x 2.0 mm x 60 teeth |
| TCB-CB | 285 mm x 2.0 mm x 80 teeth | |
| CM100 | TCB-CB | 360 mm x 2.25 mm x 60 teeth |
| TCB-CB | 360 mm x 2.25 mm x 80 teeth | |
| TCB-CB | 360 mm x 2.25 mm x 100 teeth | |
| CM150 | TCB-CB | 460 mm x 2.7 mm x 40 teeth |
| TCB-CB | 460 mm x 2.7 mm x 60 teeth | |
| TCB-CB | 460 mm x 2.7 mm x 80 teeth | |
| TCB-CB | 460 mm x 2.7 mm x 100 teeth |
TCB-SU
Circular saw blade suitable for cutting stainless steel materials
Application
- Cutting of difficult-to-cut materials
Material of tooth tips
- Carbide
Target materials
- Special purpose steels (stainless steels)
Features
- Tool tips with high toughness suitable for cutting stainless steel materials.
- Minimized adhesion of chips to prevent tooth chipping caused by chip inclusion.
| Model | Blade Type | Size |
|---|---|---|
| CM75 | TCB-SU | 285 mm x 2.0 mm x 60 teeth |
| TCB-SU | 285 mm x 2.0 mm x 80 teeth | |
| CM100 | TCB-SU | 360 mm x 2.25 mm x 60 teeth |
| TCB-SU | 360 mm x 2.25 mm x 80 teeth | |
| TCB-SU | 360 mm x 2.25 mm x 100 teeth | |
| CM150 | TCB-SU | 460 mm x 2.7 mm x 40 teeth |
| TCB-SU | 460 mm x 2.7 mm x 60 teeth | |
| TCB-SU | 460 mm x 2.7 mm x 80 teeth | |
| TCB-SU | 460 mm x 2.7 mm x 100 teeth |
TCB-PT
Circular saw blade suitable for cutting structural steel pipes
Application
- Cutting of thin-walled pipes
Material of tooth tips
- Cermet
Target materials
- Pipes containing more than 0.25% carbon (thin-walled pipes)
Features
- This blade is designed exclusively for cutting pipes. The increased number of teeth delivers the stable cutting of thin-walled pipes.
- Capable of minimizing deformation in materials and burrs in the cutting process.
| Model | Blade Type | Size |
|---|---|---|
| CM75 | TCB-PT | 285 mm x 2.0 mm x 60 teeth |
| TCB-PT | 285 mm x 2.0 mm x 80 teeth | |
| CM100 | TCB-PT | 360 mm x 2.25 mm x 60 teeth |
| TCB-PT | 360 mm x 2.25 mm x 80 teeth | |
| TCB-PT | 360 mm x 2.25 mm x 100 teeth | |
| CM150 | TCB-PT | 460 mm x 2.7 mm x 40 teeth |
| TCB-PT | 460 mm x 2.7 mm x 60 teeth | |
| TCB-PT | 460 mm x 2.7 mm x 80 teeth | |
| TCB-PT | 460 mm x 2.7 mm x 100 teeth |
TCB-TI SU
Coated circular saw blade for cutting stainless steel materials, characterized by high wear resistance
Application
- Cutting of difficult-to-cut materials
Material of tooth tips
- Carbide (and coated)
Target materials
- Special purpose steels (stainless steels)
Features
- Blade life significantly is increased by coating for cutting stainless steel materials. This model has excellent deposit resistance and wear resistance.
- Stable life and good cutting quality.
| Outer Diameter (mm) | Inner Diameter (mm) | Blade Thickness (mm) | Number of teeth |
|---|---|---|---|
| 250 | 32 | 2.0 | 72/80 |
| 285 | 40 | 2.0 | 60/80 |
| 360 | 40 | 2.6(2.5) | 60/80/100 |
| 360 | 50 | 2.6(2.5) | 60/80/100 |
Specifications may change without notice at the sole discretion of Amada’s Engineering Department.
