C916A(VFD-3) Bandsaw

Fixed or swivel head models. Manual to fully automatic operations. Whatever your application there is a DoALL C-916 series/C-1321DS cut-off saw to meet you requirements. They are American made and combine maximum performance and versatility with guaranteed cut-off accuracy of +/- 0,1 mm/100 mm of material cut.  The DoALL C-916A is a basic automatic operated band saw machine. A closed hydraulic circuit and needle valve controls the down feed, a infinitely adjustable belt and pulley drive controls the band speed between 27 and 70 m/min. With an mechanically adjustable length setting device the operator sets the required length and he programs the desired number of cuts in a piece counter. Important: this machine requires plant air.

STANDARD EQUIPMENT

-       Recirculating coolant system applied through saw guides

-       Saw guides, spring-loaded, solid carbide inserts

-       Saw blade guards

-       Powered chip brush

-       Replaceable steel wear plates on machine bed

-       Workstop and piece counter

-       Variable vice pressure

-       Instruction plate with sawing recommendations

-       Fine adjustment head feed control
