DoALL mitre cutting saws will increase flexibility and improve efficiency in sawing applications requiring cutting of miters. The 400S general purpose band saw is a new machine in the structurALL family of saws. The 400S features a 228 x 406 mm wide capacity of rectangles and 273 mm rounds at 0º. Swiveling 45º it’s the ideal machine for small to medium fabricator or machine shop, looking to make extremely accurate (straight or miter) cuts in smaller quantities. This manual machine can be equipped with a variety of options to further ease operation, such as pneumatic head-lift and pneumatic vice attachments.

STANDARD EQUIPMENT

- Swivel head to 45°
- Recirculating coolant system applied through saw guides
- Saw guides, spring-loaded, plated carbide inserts
- Gear driven band brush
- Integrated fork lift pockets
- Discharge tray
- Saw blade guards
- Rapid head down approach
- Replaceable steel wear plates on machine bed
- Band door interlocks
- Sawing data recommendation chart
- Fine adjustment head feed control
- Shovel rake

OPTIONAL EQUIPMENT

- Pneumatic head-raise
- Pneumatic vise
- Full cycle attachment
- Halogen work light
- Discharge table
- Gravity roller conveyor
- Band Mist lubricator
- Flushing hose with spray pistol
